TR 22 Trapezoidal threaded spindle steel

Robuste Trapezgewindespindeln (22mm, 5mm Steigung) für hohe Traglasten, mit langer Lebensdauer und präzisem Rechtsgewinde. Ideal für Axialkräfte.


Stock: 7
Product number: 13028.14-V00L1000
Weight: 2.25 kg
Product information "TR 22 Trapezoidal threaded spindle steel"

TR22x5 l right-hand thread l single-start l steel (11SMnPb30) rolled l length 1000mm l DIN 103 l designed for high loads

Properties trapezoidal threaded spindle TR 22x5 - steel

The trapezoidal threaded spindles have a diameter of 22mm and a thread pitch of 5mm. The spindles are available in 1 meter length. The spindle is characterized by a single-start right-hand thread and its application under high loads. The transmission of large axial forces is possible due to the trapezoidal profile of the spindle. The drive solution owes its high strength and continuous grain to the manufacturing process. The threaded rods are rolled. The ends are then sawn and not deburred. A long service life, high surface quality, backlash-free adjustment and readjustment, and low friction are further special properties of the spindles. For the optimal drive solution, we offer matching trapezoidal leadscrew nuts in our store.


TR 22x5
Right-hand thread


Length 1000mm
Material steel (11SMnPb30)

Application Trapezoidal Screw TR 22x5 - Steel

In addition to their use in fastening and clamping applications, trapezoidal lead screws help to convert a rotary motion into a linear one. Other applications include mechanical engineering, use in drives and actuators, or travel and positioning.

Besides the present threaded rods TR 22x5 in steel, other spindle sizes with matching threaded nuts are available in our store.
