Angular gear Ket-Bee 200X LxC Gearbox
| Quantity | Unit price |
|---|---|
| To 4 |
€130.95*
|
| To 9 |
€126.10*
|
| To 19 |
€121.25*
|
| From 20 |
€116.40*
|
Available, delivery time: 1-3 days
Product information "Angular gear Ket-Bee 200X LxC Gearbox"
This series of bevel gearboxes includes four different sizes and is ideally suited for a wide range of applications where an angular transmission is required. The design combines a space-saving housing with high torque transmission, rugged construction, and smooth, efficient operation. Thanks to the thoughtful screw mounting, the gearbox can be easily and quickly integrated.
Special Features
- Selectable shaft configuration: Solid shaft or blind hollow shaft
- Maintenance-free operation with low noise levels
- High-load, hardened steel bevel gears
- Aluminum housing, anodized, available in orange or silver
- 1:1 ratio in the gear transmission
- Operating temperature range: –20 °C to +60 °C
- Backlash at the output side: 3° ± 1°
- Designed for an intermittent duty cycle of 20% in 5-minute intervals (1 minute of operation, 4 minutes of rest)
- Expected lifespan: 1000 operational hours under
- full load,
- an input speed of 500 rpm,
- and a 20% duty cycle in 5-minute intervals
Technical Data
| Item.-Nr. |
Speed range n in min-1 |
Max. Torque M in Nm |
Radial and axial load* FR in N FA in N |
Weight per part in kg | ||||
|
2006.00-L0C10R1
| 100/500/1000 | 8/3/1.5 | 550 | 0.33 | ||||
|
2007.00-L0C12R1
| 100/500/1000 | 10/4/2 | 550 | 0.40 | ||||
|
2008.00-L0C12R1
| 100/500/1000 | 12/5/2.5 | 600 | 0.57 | ||||
|
2009.00-L0C12R1
| 100/500/1000 |
|
| 0.80 |
* The values for FR apply only when FA = 0 N
The values for FA apply only when FR = 0 N
