Angular gear Ket-Bee 200X T-Gearbox in synchronization/counter-rotation
| Quantity | Unit price |
|---|---|
| To 4 |
€126.70*
|
| To 9 |
€122.00*
|
| To 19 |
€117.30*
|
| From 20 |
€112.60*
|
Available, delivery time: 1-3 days
Product information "Angular gear Ket-Bee 200X T-Gearbox in synchronization/counter-rotation"
This bevel gear unit family with a continuous shaft includes 10 different sizes and is ideal as an angular gearbox for a wide range of applications. The gearbox impresses with its compact design, high torque, robustness, and efficient power transmission. Thanks to a practical screw fastening, installation is extremely easy.
Key Features
- Maintenance-free and particularly quiet in operation
- Hardened steel bevel gears for long service life
- Anodized aluminum housing for increased resistance
- Transmission ratio 1:1
- Operating temperature range from -20°C to +60°C
- Backlash at the output shaft of 3° ± 1°
- Duty cycle of 20% within a 5-minute cycle (1 minute on, 4 minutes off)
- Service life of 1000 hours under:
- Full load,
- Input speed of 500 rpm,
- Duty cycle of 20% within 5 minutes
Technical Data
| Item.-Nr. | Synchronization A Counter-rotation B |
Speed n
in rpm
| Max. torque* M
in Nm |
Radial- and
axial load** FR in N / FA in N | Part weight in kg | |
|
2000.00-T0A04R1 | Synchronization | 100/500/1000 | 0.28/0.08/0.04 | 48 | 0.03 | |
|
2001.00-T0A06R1 |
Synchronization | 100/500/1000 |
0.35/0.1/0.05 | 60 | 0.06 | |
|
2002.00-T0A06R1 | Synchronization | 100/500/1000 |
0.75/0.3/0.15 | 100 | 0.07 | |
|
2003.00-T0A08R1 | Synchronization | 100/500/1000 |
| 120 | 0.13 | |
| 2004.00-T0A08R1 | Synchronization | 100/500/1000 | 4/1.5/0.75 | 140 | 0.17 | |
| 2005.00-T0A08R1 | Synchronization | 100/500/1000 | 5/2/1 | 240 | 0.19 | |
| 2006.00-T0A10R1 | Synchronization | 100/500/1000 | 8/3/1.5 | 550 | 0.24 | |
| 2006.00-T0B10R1 | Counter-rotation | 100/500/1000 | 8/3/1.5 | 550 | 0.24 | |
| 2007.00-T0A12R1 | Synchronization | 100/500/1000 | 10/4/2 | 550 | 0.4 | |
| 2007.00-T0B12R1 | Counter-rotation | 100/500/1000 | 10/4/2 | 550 | 0.4 | |
| 2008.00-T0A12R1 | Synchronization | 100/500/1000 | 12/5/2.5 | 600 | 0.59 | |
| 2008.00-T0B12R1 | Counter-rotation | 100/500/1000 | 12/5/2.5 | 600 | 0.59 | |
| 2009.00-T0A12R1 | Synchronization | 100/500/1000 | 14/6/3 | 750 | 0.8 | |
| 2009.00-T0B12R1 | Counter-rotation | 100/500/1000 | 14/6/3 | 750 | 0.8 |
* Attention: With 200X.00-TXB variants, the drive torque is distributed over 2 axes
** The values of FR apply only when FA = 0 N
The values of FA apply only when FR = 0 N
